PREMIUM SONICS… WHEN SPACE IS AT A PREMIUM.

High quality 6.5” wide range driver for low & mid frequencies modified in house, Horn loaded super tweeter with nico magnet for high frequencies.

PRIME, a two way design, with the smallest footprint possible to house a bass horn. Bass horn fires to the floor using our mass loading technique and it’s build entirely of grade A Baltic birch plywood. Mid frequencies are radiated directly by the wide range driver cone, while the high frequencies are handled by a horn loaded super tweeter.

On the horn build, special care has being given for minimal losses, uniformly distribute the energy build up, routing and grounding.

The crossover point is set well above the critical mid range and it’s of 1st order, exhibiting zero phase shift. The crossover parts are hard wired for best contact and the board is located at the bottom of the bass horn well away from the magnetic fields of the drivers.

All internal wiring are custom made in house of high purity OFC copper with waxed cotton insulation.


TECHNICAL DATA

  • System Sensitivity: 93db
  • Impedance Nominal: 8ohms
  • Crossover: @ 6300HZ
  • Recommended Power: > 8watt
  • Recommended Amplifiers: low-mid powered tube or solid state with low or no feedback.
  • Recommended Placement: near wall or room corner.
  • Preferred clearance between speakers: >1.5 m.
  • Listening Distance: >2 m.
  • Dimensions: H116cm, W28cm, D49cm
  • Weight:  33Kgr each

We offer customer selected finish of any color paint or natural wood veneer.
